Power Amplifier 9011

The 9011 features everything that its smaller sibling, the 9008 A, has to offer – and then some. It begins with the delivery of more long-term power output and short-term current distribution, a feat achieved by way of three groups of eight output transistors each, eight electrolytic and charging capacitors, plus a third 400VA toroidal transformer to further increase charging speed and facilitate speaker load matching.

he MBL 9011 delivers the full spectrum of front-row, concert-like sound reproduction from your cherished music.

£ 46,300

The 9011 at a glance

  • Designed as a differential-balanced mono block amplifier, but can also be used as a stereo power amplifier in single-ended mode

  • Combination of Class A and Class AB amplification

  • Direct, high-precision signal processing by Direct Push-Pull technology

  • Unparalleled resolution of the finest musical nuances

  • Sound tuning/speaker impedance matching via two separate switchable power transformers

  • Two separate power input sockets

  • Extremely quiet signal ground by means of fully symmetrical signal flow from the input to the output

  • Power transistors located on a foundation of vibration-impeding solid copper

  • Compensation of all transistor non-linearities by means of unique Isolated Gain Cell circuit

  • Sixteen output devices deliver 840 watts of musical power (at 4 Ω) with an output current of 50 amps, maximum pulse power: 5,000 watts (at 2 Ω)

  • Six high-quality, in-house manufactured solid copper connecting terminals with the option of bi-wiring

  • Weight of 95 kg (215 lbs)

Technical Specifications

Pulse power (Mono/Stereo) 5 000 / 2 400 W (2 Ω)
Musical power (Mono/Stereo) 1390 / 330 W (2 Ω) 840 / 210 W (4 Ω) 440 / 130 W (8 Ω)
Input impedance 20 kΩ, XLR (Mono) 10 kΩ, RCA (Stereo)
Output current Max. 50 ampere
Weight 95 kg / 215 Ibs
