Key Features

• By using only top quality components and combining low-feedback design with high current delivery, this design will make you believe the music is being played live in the room. The Angel 4 is designed to drive mainstream loudspeakers to high levels, where other amplifiers start to compress and sound strained.

• We extend our low-feedback philosophy to the power supplies. The low-feedback amplifier is fed with incredibly pure, high current DC rails from low-feedback regulators.

• The heavy machined casing uses different panel thicknesses to damp each other out and avoid vibration reaching the amplifier components.

• The highly linear output stage uses 4 ring-emitter transistors to share the current load and remain linear, even when supplying large currents to keep a grip on the speakers.

• The Angel-4 combines the world of pure low-feedback with the high output currents needed to deliver the whole authentic musical performance. It delivers musicality and subtlety along with power, scale and dynamics. It delivers Music!

Product Specifications

Output Power
75W RMS per channel into 8 ohms
150W RMS per channel into 4 ohms

Distortion
(with typical loudspeaker load)
THD: < 0.01%
IMD: < 0.01%

Loudspeaker Outputs
Nominal: 4 ohm to 16 ohm
Connections: Wired, Spade or 4mm plug

Inputs
RCA (phono) inputs:
1V rms for full output
Input Impedance 15k ohm

Frequency Response
5Hz to 50kHz +/- 1dB

Protections
Short Circuit or Overload: +/-15A max
Overtemperature: +55C
Undertemperature: +5C

Measurements
Amplifier dimensions:
Width 430mm x Depth 340mm x Height 120mm
Weight 16kg

Packaged dimensions:
Width 490mm x Depth 420mm x Height 170mm
Weight 18kg

Mains Power
IEC inlet cable for 230V AC 50Hz mains
Optional 115V AC 60Hz version available

Power Consumption:
Maximum 650VA
Idle 50VA
Standby < 0.5W
